Geometry Preparation

FEMAP Geometry Preparation cleans-up the geometry for easier model meshing. This tool automatically simplifies imported 3D CAD geometry by cleaning, suppression, combination and removal of unnecessary or problematic geometry details and on this way helps to generate a solid model mesh. For automatic mesh FEMAP uses here 3D tetrahedral solid elements.

Please look at the video, which shows how it can be done.
